It is used to fine and medium-sized crush of abrasive material, refractory material, cement, quartz sand, steel grit, pulverized slag powder, copper ore, iron ore, corundum, concrete aggregate，bituminized aggregate etc.
It is used to fine and medium-sized crush of abrasive material, refractory material, cement, quartz sand, steel grit, pulverized slag powder, copper ore, iron ore, corundum, concrete aggregate，bituminized aggregate etc. It is a kind of rock crushing machine with high efficiency and low power consumption. As the most advanced crusher in the world, it can save 60% power when compare to traditional fine crusher.
The rotor rotating with high speed under the drive of motor, the feeding material transferred to the first crushing cavity meet the board hammer on the rotor; then the material transferred to second crushing cavity; finally ,the material discharged from the discharging port.
Send E-mail:
sales@daiwomining.com
(1) Small material-out size, simple craftwork, well-distributed particle size, large capacity of production.
(2) Head of hammer with long life and low power consumption.
(3) Simplified craftwork, simple structure, easy maintenance, stable working ability.
(4) Compare to the traditional craftwork in same scale, this machine will save 45%-65% investment, the out-put rate will be improved 40%-60%, and the fees of long-term maintenance will be reduced 30%-50%.
| Fine crusher | Rotor ￠*Width (mm) | Rotor ￠*Width (mm) | Rotor ￠*Width (mm) | Rotor ￠*Width (mm) | Rotor ￠*Width (mm) |
| Model | 800*400 | 800*600 | 800*800 | 1010*1010 | 1200*1200 |
| Feed Opening(mm) | 400*185 | 500*250 | 550*330 | 1000*350 | 1200*450 |
| Feed Size (mm) | <120 | <180 | <180 | <180 | <180 |
| Discharge Size(mm) | <5 | <5 | <5 | <5 | <5 |
| Adjust Distance of Discharge Sieve | 5-20 | 5-20 | 5-20 | 5-20 | 5-20 |
| Cement clinker(T/H) | 20-30 | 35-40 | 35-45 | 45-55 | 100-110 |
| Limestone(T/H) | 35-45 | 45-55 | 55-65 | 65-75 | 90-100 |
| Pebble(T/H) | 20-30 | 35-40 | 35-45 | 35-55 | 40-100 |
| Power(Kw) | 37-45 | 45-55 | 45-55 | 110 | 132 |
